Product Introduction
HJ Vertical mill is one kind of roller mill. As requested, it may equip with 3 or 4 rollers. Each roller is composed of fixed roller, support of installation rocker arm and hydraulic system. Motive force unit is in the whole or a standard part. It can be arranged in two components, three components or four components around mill disc.
Features
- low noise.
- Low energy consumption.
- Quick control response.
- The vibration is small from start to stop.
- Strong adaptability.
- Small covering area.
- Easy adjustment.
- Excellent dry grinding capacity.
- Easy maintenance (no need to dismantle and can replace easily worn-out parts).
Technical Parameter
| Model | Grinding Table Diameter (mm) | Motor (kW) | Output (t/h) |
|---|---|---|---|
| RMS19 | 1900 | 560 | 15 |
| RMS23 | 2300 | 710 | 20 |
| RMS26 | 2600 | 1000 | 28 |
| RMS30 | 3000 | 1400 | 40 |
| RMS33 | 3300 | 1600 | 45 |
| RMS36 | 3600 | 2000 | 60 |
| RMS38 | 3800 | 2240 | 65 |
| RMS40 | 4000 | 2500 | 75 |
| RMS43 | 4300 | 3000 | 90 |
| RMS46 | 4600 | 3150 | 95 |
| RMS50 | 5000 | 4000 | 125 |
| RMS53 | 5300 | 4500 | 145 |
| RMS56 | 5600 | 5000 | 155 |
| RMS60 | 6000 | 6300 | 180 |
| RMS65 | 6500 | 7300 | 220 |
| RMS70 | 7000 | 8500 | 260 |
